BLDC Direct Drive Motor Roller
Brand: BONRAY
Product origin: Dalian
Delivery time: 25 days after recieving payment
BLDC direct drive permanent magnet motor roller is integration of motor drive and roller. The rotation of the roller is directly driven by the built-in motor and the cylinder of the roller is the rotor.
The optimized design of internal permanent magnet motor achieves innovative high-efficiency direct drive applications.
It is applied for automatic sorter and AGV conveyor widely.
Permanent Magnet Motor Roller Introduction
BLDC direct drive permanent magnet motor roller is integration of motor drive and roller. The rotation of the roller is directly driven by the built-in motor and the cylinder of the roller is the rotor.
The optimized design of internal permanent magnet motor achieves innovative high-efficiency direct drive applications.
It is applied for automatic sorter and AGV conveyor widely.
BLDC Motor Roller Characteristics:
For high speed, direct drive, large torque,energy saving and quick corresponding speed application
BLDC Motor Roller Advantages:
1. Applied for automatic sorter, GTA PM motor roller reduces sorter trolleys’ weight, increases space availability and sorting efficiency.
2. GTA PM motor roller controller has updated 15 times until now and can be adjust to various interference and compatible with other parts better.
3. Over 120000 GTA PM motor roller have been operating stably for over 6 years in high-end express and e-commerce market.
4. Own CE authentication.
5. Easy installation and control.
Successful Case:CHINA POST
All automatic sorters of CHINA POST use our BLDC direct drive motor rollers!
With the rapid development of e-commerce, we have provided more than 1250 baggage handling components and spare parts for postal sites, e-commerce sites and intralogistics transmission sites around the globe, including big names such as AMAZON, JD.com, CHINA POST, SF EXPRESS, DELHIVERY, YTO, ZTO, STO etc.
Permanent Magnet Motor Roller Specification
Item | Specification | Note |
Roller OD | 67mm / 50mm | |
Voltage | DC 48 +/- 10% | |
Power | 400 w | |
Rotate speed range | 300-750 r/min | |
Line speed | 1-2.6 m/s | |
Sorting weight | 0-40 kg | (For heavy load 0-40KG) |
Rated torque | 1.5 N.m | |
Max torque | 5 N.m | ≤4 s |
Duty cycle | S2--25% | |
Position control mode | Hall | |
Reaction speed | ≤0.03 s | |
Communication mode | RS485 |
Motor roller Inspection:
All motor rollers have tracking checklist, which can be traced back to the size of each part. Motor roller ends have separate serial number, which can be traced back to all testing data. Drivers also have sticking bar code serial number on their side. Motor insulation performance test includes voltage resistance and inter-turn testing. Motor performance test adopts back EMF method. 100% inspection before delivery. All drivers are verified by logic. Actual driving test and aging test are passed before delivery.
Our Factory:
Advanced equipments ensure our excellent quality.
Packages:
Each powered roller is separated by a partition to avoid collision.
There are pallets under cartons for easy shipment.
Patent and CE certificates:
The first BLDC direct drive motorized roller for cross belt sorter in Chinese market is from our company!
The first powered roller and linear motor we provided to CHINA POST has been operating for over 5 years and is expected to be in good run for many more.
Our R&D team has more than 6 years' expertise in the relative technical fields. Gaining credit from its products such as powered rollers, linear motors and sorters, Bonray took the No.1 market share in China’s conveyor transmission industry since 2016.
Bonray is always looking forward to helping customers in improving their logistics efficiency while prolonging service life of conveyor transmission systems!
